Antenna PCB RO4350B High Frequency 4 Layer ENIG Board

Antenna PCB RO4350B High Frequency 4 Layer ENIG Board Model: Ro4350B Ceramic Hybrid High Frequency PCB Material: Rogers RO4350B+FR4 Mixing Press Layer: 4L D K: 3.48 Finished Thickness: 1.0MM Copper Thickness: 1OZ Dielectric Thickness: 0.762mm Thermal Conductivity: 0.69w/m.k Flammability: V-0 Surface Treatment: Immersion Gold Application: Radio Frequency, Microwave Antenna Product Details Material Composition The Antenna PCB RO4350B High Frequency 4 Layer ENIG Board is crafted using a unique blend of Rogers RO4350B and FR4 materials. Rogers RO4350B, a ceramic-filled polytetrafluoroethylene (PTFE) composite, is renowned for its low loss tangent and stable dielectric constant, making it ideal for high-frequency applications. Mixed with FR4, a standard flame-retardant epoxy glass-cloth laminate, it provides both mechanical strength and cost-effectiveness. Performance Characteristics · Dielectric Constant (Dk): 3.48, ensuring consistent signal propagation and minimal signal los…
